Northern Tool + Equipment

Modernizing a high-traffic e-commerce platform — accessible, research-backed, and still live four years on.

Overview

The problem

Northern Tool’s HCL Commerce site had aged out of its own design — built before accessibility was mainstream, and no longer matching how people actually shop. The catch: marketing had locked the black-and-yellow palette. The brief was to rebuild to modern e-commerce and WCAG 2.1 AA standards, without reaching for color.

Role & duration

I joined to advise on Axure and stayed as lead designer and front-end developer for the build — owning UX research and design, prototyping, the SCSS and TypeScript theming, accessibility testing, and mentoring EY’s offshore front-end team.

2021 — 2022

The team

The best part of this project was the Northern Tool UX team — a shared bar for craft, easy communication, and enough mutual trust to head off the gaps that stall projects before they start. Good work comes from good working relationships; this was one of the good ones.

Research

Research-led UX — Baymard Premium

The Northern Tool team had a real commitment to research-backed design and accessibility, backed by extensive Baymard Institute’s Premium e-commerce research — the field’s most rigorous body of e-commerce UX evidence, drawn from over 130,000 hours of usability testing at the time. I got to build on that foundation rather than argue for it, which is rare and worth naming.

Baymard Premium Screenshot
The Baymard Institute’s Premium Research played a key role in steering the direction of the UX design

The readability system

I created a SCSS-based readability framework, based on The 8 Point Grid System, with the palette locked to black and yellow so structure had to carry the clarity color usually does:

  • Line length held to ~70 characters
  • Deliberate line spacing for maximum legibility
  • Clear type hierarchy by size, weight, and position
  • Left-aligned text; no all-caps, no underlined non-links
  • Responsive resizable text for accessibility
Side by side: the category index page as an Axure wireframe with gray placeholder cards and breakpoint tabs from XL 1440 to XS 360, and the same page live with product photos, type hierarchy, and spacing carried through.
Wireframe to shipped page: the category index in Axure, planned across five breakpoints, and the same page live in SCSS, with the cards, type hierarchy, and spacing carried straight through.

Constraints

Building JavaScript components in a CMS with no JavaScript

HCL Commerce's content management system didn't support JavaScript, meaning there was no straightforward way to build the interactive components a modern e-commerce site needs. So I built one: a framework of TypeScript utilities that scan each page for specific HTML classes and activate behavior from them, documented in Storybook so the content team could use it.

A Sample of the NTE Custom CMS Class Based Components:

  • Grid (structure) Layout and Flex (content) Layout
  • Carousels
  • Modal Dialogs and Drawers
  • Media Windows
  • Custom Banners (with and without background image)
  • Responsive Background Images and Responsive Spacing Classes

Even the browsers pushed back: Safari couldn't size video by aspect ratio yet, so the framework carried its own fallback, one custom property that kept every embed in proportion.

The framework's Storybook documentation for accordions: plain-language rules, the HTML pattern editors write with the accordion, header, and content classes, and a working FAQ page built from it.
The framework's own documentation in Storybook: the HTML pattern an editor writes in HCL Commerce Management Center (CMC), then the working FAQ it produces. The button element is there for keyboard and screen-reader users.

Keeping the project moving

The next obstacle was thornier. For the first six months, a brand-new HCL Commerce 9.0 backend was too raw to reliably surface the data we needed to theme against — and the timeline didn’t allow for building mock data. That left me unable to theme and the front-end team stalled without components.

Rather than wait, I used the site’s own scale as the way out. Every morning’s scrum became a hunt for whichever sections were workable — content pages, banners, accessibility passes on finished work — and I kept progress there. On a site that large, there was always another corner to move forward in.

Outcome

The accessibility lesson

Northern Tool commissioned two accessibility audits. Partway through, I flagged that our React-fluent team was writing HTML that would fail review, and recommended a short expert code pass. It didn't happen when I proposed it — and those issues later surfaced as roughly three months of remediation. Accessibility is least expensive when it's caught first, not last.

What's held up

After remediation, the site passed its second audit at WCAG 2.1 AA and shipped on the original black-and-yellow palette — proof the constraint was never the obstacle. The class-triggered framework gave a JavaScript-less CMS a modern, documented component library. And the clearest measure of the work: the theme is still live in production four years later, maintained and evolving. Design that held up.

The readability system outlasted the project, too. I kept refining it, and today it's octet-scss, an open-source SCSS framework: the same grid, line lengths, and type hierarchy, rebuilt so any project can use them.
